HY208-1-90V-SS
Dimensions: (Inches)
| O.D. | I.D. Top | O.A.L |
|---|---|---|
| 1.75 | 0.98 | 8.2 |
Construction:
Viton, 304 SS Construction
Beta Rating:
Beta 2.5[c] >= 1000 (ISO 16889 & DFE)
Gasket Material:
Viton
End Cap:
304 SS
Adhesive:
Epoxy
By-Pass:
NONE
Media Type:
Microglass supported both sides
Gasket Type:
O-Ring
Inner Core:
304 SS
Flow Direction:
OUT to IN
Quantity Per Case:
1
Individual Filter Weight:
1lbs
Operating Limits:
- Recommended Change Out: 25 PSID
- Maximum Temperature: 250 °F
- Collapse Rating: 290 PSID
