HY2101-60W-43HDV
Dimensions: (Inches)
| O.D. | I.D. Top | O.A.L |
|---|---|---|
| 1.74 | 1.02 | 9.65 |
Construction:
SOE, O-Ring
Nominal Efficiency:
60 Micron
Gasket Material:
Viton
End Cap:
Corrosion Resistant CS/AL
Adhesive:
Epoxy
By-Pass:
NONE
Media Type:
Stailess Steel Wire Mesh
Gasket Type:
O-Ring
Inner Core:
Plated CS
Flow Direction:
OUT to IN
Quantity Per Case:
1
Individual Filter Weight:
1.5lbs
Operating Limits:
- Recommended Change Out: 25 PSID
- Maximum Temperature: 225 °F
- Collapse Rating: 3000 PSID
