HY304-10-50CLV
Dimensions: (Inches)
| O.D. | I.D. Top | I.D. Bottom | O.A.L |
|---|---|---|---|
| 3.1 | 1.7 | 1.7 | 4.5 |
Construction:
Viton, Coreless, DOE
Beta Rating:
Beta 12{c} >= 1000 (ISO 16889 & DFE)
Gasket Material:
Viton
End Cap:
Epoxy Coated CS
Adhesive:
Epoxy
By-Pass:
NONE
Media Type:
Microglass supported both sides
Gasket Type:
O-Ring
Inner Core:
NONE
Flow Direction:
OUT to IN
Quantity Per Case:
1
Individual Filter Weight:
1lbs
Operating Limits:
- Recommended Change Out: 25 PSID
- Maximum Temperature: 250 °F
- Collapse Rating: 100 PSID
