HY608-1495W-83B
Dimensions: (Inches)
| O.D. | I.D. Top | I.D. Bottom | O.A.L |
|---|---|---|---|
| 5.97 | 4.13 | 4.13 | 8.1 |
Construction:
Buna O-Ring, DOE, SS Mesh
Nominal Efficiency:
149 Micron
Gasket Material:
Buna
End Cap:
Plated CS
Adhesive:
Epoxy
By-Pass:
NONE
Media Type:
Stailess Steel Wire Mesh
Gasket Type:
O-Ring
Inner Core:
Plated CS
Flow Direction:
OUT to IN
Quantity Per Case:
1
Individual Filter Weight:
4lbs
Operating Limits:
- Recommended Change Out: 25 PSID
- Maximum Temperature: 225 °F
- Collapse Rating: 150 PSID
