Dependable Performance:
AFT’s advanced Multi layer Dual-Phase Micro-Glass pleated media is certified to be Beta x[c] = 1000 in accordance with ISO 16889 and Dynamic Filter Efficiency (DFE) testing. Media is supported both upstream & downstream by an epoxy coated c.s. mesh. AFT media provides high flow rates, low pressure drop and stable & dependable Beta x[c] rated efficiencies.
Â
Versatility:
- 2.5u, 3u, 6u, 12u & 25u Beta x[c] 1000 rated efficiencies per ISO 16889 & DFE
- Stainless Steel Mesh: 25, 40, 50 60, 74 & 149 micron
- 150, 250, 450 and 3000 psid collapse rated construction per ISO 2941
- Integral By-Pass assembly is available on some series
- Operating Temperature from -45f to 250f
- Buna, Fluorocarbon, EPR & Silicone O-Ring Seals
|
Applications:
- Petroleum & Synthetic based Hydraulic Fluids
- Turbine & Compressor lube oil
- Bearing & Gear oil
- Custom OEM designs & Private Branding
- Cost effective replacement for Expensive OEM elements
|
